HD-TVI CCTV 1080P Vari-focal IR Bullet Camera DG205X
Model: DG205X
- 1/ 2.9” CMOS Sensor
- 1080P video output
- f2.8 ~ 12mm vari-focal lens
- Low light sensitivity of 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0 Lux (IR LED ON)
- Day and night 24-hour surveillance with IR effective distance up to 25 meters
- IP66 for weather-proof application
- Camera parameters adjustable when used with AVTECH HD CCTV DVR
| Pick-up Element | 1/ 2.9” CMOS image sensor |
| Number of Pixels | 1936(H) x 1096(V) |
| Video Frame Rate | 1080P@30fps / 1080P@25fps |
| Min. Illumination | 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0 Lux (IR LED ON) |
| S/N Ratio | More than 48dB (AGC OFF) |
| Shutter Speed | 1/30 (1/25) sec ~ 1/33750 (1/28125) sec |
| Lens | f2.8 ~ 12mm / F1.4 ~ F2.8 |
| Lens Angle | Wide: 103° (Horizontal) / 54° (Vertical) / 122° (Diagonal) Tele: 31° (Horizontal) / 17° (Vertical) / 36° (Diagonal) |
| IR LED | 36 units |
| IR Effective Distance | Up to 25 meters |
| IR Shift | Yes |
| Day & Night Mode | Yes |
| IRIS Mode | AES |
| White Balance | AUTO / INDOOR/ OUTDOOR/ USER / PUSH |
| AGC | High / Middle / Low / Off |
| Sharpness | Adjustable |
| IP Rating | IP66 |
| Operating Temperature | -25ºC ~ 50ºC |
| Power Source (±10%) | DC12V / 1A |
| Current Consumption (±10%) | 210mA (IR OFF); 520mA (IR ON) |
* The specifications are subject to change without notice.
