3.5 Inch Handsfree Color Monitor CDV-352HD

Model: CDV-352HD

  • 3.5 inch TFT LCD screen
  • Easy installation with 2 wiring method with non-polarity
  • Handsfree function
  • Runs on DC 24V
  • Video talk and door lock release enable (both individual and public entrance)
  • Support 2 Monitor, 2 Camera and 2 Interphones
  • PAL/NTSC convertible
  • 2 WIRING METHOD2 WIRING METHOD

    Easy installation with 2 wiring method with nonpolarity.

  • VIVID DISPLAY ANDVIVID DISPLAY

    It leads the world color video phone markets providing undistorted clear view and outstanding quality.

  • LED BACKLIGHTLED BACKLIGHT

    Provide vivid pictures by utilizing LED backlight.



Model CDV-352HD
Wiring
  • To entrance: 2 wires
  • To interphone: 4 wires
Rated Voltage 24V 1A
Screen Color 8.89cm (3.5") TFT LCD
Call sound
  • From a door camera: Electric chime Sol Mi Do (twice)
  • From an interphone: Electric chime
Power Consumption
  • Standby: 2W
  • Operation: Max 10W
Connection distance
  • A door camera unit to CDV-352HD: 50m/Ø0.65
  • Interphones to CDV-352HD: 30m /Ø0.65
Operating temperature 0ºC ~ 40ºC
